Sidewinder chassis offset 1mm EVO6

Fine-tune the geometry of your rear end with the 1 mm offset EVO6 sidewinder motor mount

The SICH65 mount is a specific preparation piece for sidewinder setups with short-can motors. Its 1 mm offset allows lateral displacement of the motor-crown assembly to precisely adjust the pinion engagement, rear axle alignment, and mass distribution in the chassis.

Function and performance

In a sidewinder setup, the motor is positioned parallel to the rear axle. The mount is the element that secures and positions the motor within the chassis, and any variation in its geometry directly affects the car's behaviour. The 1 mm offset of this EVO6 mount allows:

• Adjusting the contact between pinion and crown without the need to modify the chassis.
• Correcting minor misalignments of the rear end.
• Optimising power transmission by reducing friction losses.
• Adapting the motor position to different short-can motor chassis configurations.

Compatibility

This mount is designed for short-can motors in a sidewinder configuration. If you have doubts about whether it fits your chassis or motor-crown combination, we recommend checking the dimensions with the manufacturer before installation.

Installation and preparation

Installing an offset mount requires some experience in slot car preparation. Before permanently securing it, it is advisable to check the pinion-crown engagement play with the assembled car and run it briefly to detect any potential rubbing. An engagement that is too tight or too loose will penalise both top speed and the durability of the parts.

Frequently asked questions

What does "1 mm offset" mean in a mount?

The offset indicates the lateral displacement of the motor mounting axis relative to the standard position. In this case, 1 mm to one side, allowing for variation in the pinion position in relation to the crown to achieve optimal engagement.

What type of motor is this mount for?

It is designed for short-can motors in a sidewinder configuration, meaning the motor is arranged parallel to the rear axle of the car.

Is it compatible with all short-can sidewinder chassis?

Not necessarily. Mounts are components with very tight tolerances. Always check that the mounting dimensions match your chassis before proceeding with installation.

Can I combine it with different crowns and pinions?

Yes, but the offset determines which combination is most suitable. Always start from a defined gear ratio and check the engagement with the mount already placed in its final position.

Is it a part for competitive use or also for recreational use?

It is primarily aimed at preparation and competition, although any enthusiast looking to optimise the performance of their slot car can use it with good results.

The SICH65 EVO6 sidewinder motor mount features a 1 mm offset designed for short-can motors, allowing precise pinion-to-crown alignment in slot car preparation. An essential upgrade for competitive slot car racing, chassis tuning, and drivetrain optimisation in sidewinder configurations.
