PINION EXTRACTOR

The silent ally of any well-equipped slot workshop

There are tools that make the difference between a careless preparation and a truly professional job. The CXM060 pinion extractor is one of them. Specifically designed to remove pinions from the axle without resorting to brute force, it prevents damage that a poor disassembly can cause to both the pinion and the axle itself.

Function and performance

The purpose of this extractor is clear: to apply the necessary force in a controlled and centred manner on the pinion, so that it comes off the axle without deformation, marks, or compromising the integrity of the assembly. In slot racing, where axles operate with very tight tolerances, a damaged pinion or a slightly deformed axle can result in vibrations, noise, or loss of traction.

Compared to the usual alternatives—levers, screwdrivers, and improvised pliers—the CXM060 offers a clean and repeatable procedure. Ideal for both the enthusiast who frequently assembles and disassembles cars and the preparer who works with several chassis in parallel.

Compatibility and applications

This extractor is designed for use with the common pinions and axles in the slot world. It is compatible with the most widespread formats, making it suitable for working with cars from brands such as NSR, Slot.it, Scaleauto, Avant Slot, and others that use standard-sized axles and pinions.

It is particularly useful when working on:

• Changing gear ratios to adapt the car to different circuits.
• Replacing worn or damaged pinions.
• Preparing chassis for competition, where precision in the drivetrain is crucial.
• Periodic checks of the rear end in club or race cars.

Assembly and preparation

The use is straightforward: place the extractor over the pinion with the axle correctly positioned in the tool's housing and apply pressure progressively. The design ensures that the force acts axially, without tilting or forcing the pinion in any direction. In a few seconds, the pinion is free without having suffered any damage.

Before using the extractor, it is advisable to clean the axle of adhesive residue or accumulated dirt, as these can increase resistance to disassembly and hinder the process.

Common mistakes this tool prevents

• Marking the axle with pliers: one of the most common damages when trying to extract a pinion by hand or with inadequate tools. With the CXM060, the axle does not receive any lateral pressure.
• Deforming the pinion: by applying force in a centred and axial manner, the pinion comes out intact and can be reused if it is in good condition.
• Bending the axle: the greatest risk of working without the correct tools, which this tool completely eliminates when used correctly.

Frequently asked questions

What exactly is a pinion extractor for?

It allows you to remove the pinion from the rear axle of a slot car without damaging either piece. It is especially useful when the pinion is tightly fitted or has been mounted for a while and has generated some adhesion.

Do I need prior experience to use the CXM060?

No. Its use is intuitive and does not require advanced technical knowledge. Any enthusiast who performs their own assemblies can use it without difficulty.

Can I reuse the pinion once extracted?

If the pinion is in good condition and the extractor has done its job correctly, yes. The advantage of this tool is precisely that it does not damage the piece during extraction.

Is it compatible with all pinion sizes?

It is designed for the common pinion formats in slot 1/32 and similar. If you have doubts about compatibility with a specific pinion, please consult us before placing your order.

How often should I use this tool?

Whenever you need to disassemble the pinion from the axle, whether for a gear ratio change, a check, or a replacement. There is no fixed interval: it depends on how regularly you work on the drivetrain of your cars.

The CXM060 pinion extractor is a precision workshop tool designed for slot car hobbyists and competitive racers who need to remove pinion gears from axles cleanly and without damage. Compatible with standard slot car axle sizes from brands such as NSR, Slot.it, Scaleauto and Avant Slot, it prevents common mistakes like bent axles or deformed pinions caused by improvised tools. An essential addition to any serious 1/32 slot car workbench.
